| Size parameters | Dimensions (LxWxH) | 10700X3400X3580 | Performance parameters | Rated power (kw/min) | 309/2200 |
| Wheelbase(mm) | 5000+3000 | Maximum torque (N m/min) | 1750/1300-1600 | ||
| Front suspension/rear suspension(mm) | 1200/1500 | Displacement (L) | 12 | ||
| Wheel base (front/middle/rear) (mm) | 2690/2670/2670 | Maximum speed (km/h) | 95 | ||
| Approach / departure angle(º) | 50/34 | Minimum stable speed (km/h) | 3.5 | ||
| The height of the upper plane of the frame from the ground (full load)（mm） | Front axle 1600, rear axle 1680, soil 30 error | 0-60km/h acceleration time (s) | ≤30 | ||
| Quality parameters | Curb weight (kg) | 13000kg | Maximum grade(% ) | 60 | |
| Maximum allowable gross mass of chassis (kg) | 41000 | Slope holding capacity (%) | 40 | ||
| Maximum allowable axle load (kg) | Front axle 9000, middle axle 16000, rear axle 16000 | Minimum ground clearance (mm) | 605 (lower end of front axle housing) | ||
| Drive form | 6X6 | Minimum turning radius (m) | ≤10 | ||
| Maximum vertical obstacle clearance height (mm) | ≥1000 | ||||
| Maximum cross trench width (mm) | ≥1000 | ||||
| Maximum wading depth (mm) | ≥1500 | ||||
| Fuel consumption per 100 kilometers under limited conditions (L) | ＜40 | ||||
| Fuel tank volume (L) | 120 | ||||
